Machine usage :
Bopp tape pillar package machine can pack opp tape by 6 rolls or 4 rolls together, then shrink tape roll with PE shrink film.
Bopp tape package Machine feature:
1. The machine can complete multi-layer or multi-roll combined packaging according to production requirements
2. Adopt Siemens PLC controller to Realize electro mechanical integration
3. Different packing type can be set on touch screen,also can count the production quantity
4. Adopt imported sealing knife,sealing line is firm,not easy to stick
5. The material is transported by belt, stable and fast.
6. Adopt Omron photoelectric positioning ，make material accurate position.
7. This machine can adjust mould according to the material size,no need to change mould saving time
8. Adopt separated structure, can choose suitable shrink oven according to different material size.
9. Using induction type cutter to reduce waste
Opp tape package Machine specification：
| Model | GD901 |
| Material size（L）mm | 90-330 |
| Material size（W）mm | 50-160 |
| Material size（H）mm | 50-160 |
| speed（piece/min） | 8-25 |
| Temperature | 0-200 |
| Max cutting film size(mm) | 600 |
| power（kw） | 1.2 |
| Gas source（kg/cm²） | 6-8 |
| Machine weight（kg） | 400 |
| Machine size（L*W*H）mm | 2400*1200*1700 |
